Overview
The Kupo Jumbo Cranking Stand (756M) is a professional ultra heavy-duty wind-up stand designed for safely supporting extremely large lighting fixtures and production equipment in film, television, studio, and broadcast environments. TÜV certified for safety and reliability, it is engineered for high-load applications where precision, stability, and operator safety are critical.
Built from chrome-plated steel, the 756M features a direct-drive gear mechanism and integrated automatic self-locking system, allowing controlled, cable-free lifting of heavy equipment. This system ensures smooth operation while eliminating the risks associated with traditional pulley-based designs.
With a maximum load capacity of 70 kg and a working height of up to 6.1 m, this stand is ideal for high-output lighting setups, large fixtures, and demanding studio or location work. Each riser includes oversized ergonomic T-handles for maximum torque and precise height control.
The stand is equipped with a wide footprint base for maximum stability, integrated 6-inch braked caster wheels for safe mobility, and wind-bracing eyelets for additional rigging security in outdoor or high-wind environments.
Key Features
• TÜV certified ultra heavy-duty professional wind-up stand
• Chrome-plated steel construction for maximum durability and strength
• Supports up to 70 kg load capacity for large lighting fixtures and rigs
• Maximum height of 6.1 m for high overhead production lighting
• Direct-drive gear mechanism for smooth, controlled lifting without cables
• Automatic self-locking system prevents unintended lowering of load
• 4 risers / 5-section telescopic column design for stable vertical extension
• Oversized T-handles for high-torque adjustment on each riser
• Wide 2.1 m footprint for maximum stability under load
• Integrated 6" braked caster wheels for safe movement and locking
• Junior (1-1/8") receiver with wind-bracing compatibility
• Wind-bracing eyelets for additional safety rigging in outdoor conditions
Specifications
• Maximum Height: 6.1 m
• Minimum Operating Height: 1.93 m
• Closed Length: 2.30 m
• Load Capacity: 70 kg
• Weight: 71 kg
• Sections: 5
• Risers: 4
• Column Diameters: 90 mm / 80 mm / 70 mm / 60 mm / 50 mm
• Footprint Diameter: 2.1 m
• Tube Size: 30 × 30 mm
• Mount: 1-1/8" Junior receiver with wind-brace bracket
• Mobility: 6" (152 mm) braked caster set included
• Material: Chrome-plated steel
What’s in the Box
• Kupo Jumbo Cranking Stand (756M)
• Integrated 6” braked caster wheel set
• Detachable ratcheted crank handle
• Safety rope set (x3)
