Overview
The Nanlux NL Mount Projection Attachment 15–30° is a professional optical light-shaping accessory designed specifically for Nanlux Evoke series LED spotlights. Engineered for high-end film, television, commercial, broadcast, and studio productions, it provides precise control over beam angle, focus, shutter cutting, and gobo projection while significantly increasing fixture output. Compatible with the Evoke 900C, Evoke 1200, Evoke 1200B, and Evoke 2400B, this projection attachment transforms powerful LED fixtures into highly controllable spotlight systems for creative and technical lighting applications.
Featuring a precision-engineered aspherical optical lens system, the Projection Attachment delivers exceptional beam uniformity while minimising chromatic aberration, distortion, and unwanted light spill. The adjustable 15°–30° zoom range allows lighting professionals to precisely shape and focus illumination without repositioning the fixture, making it ideal for projecting patterns, creating textured backgrounds, highlighting architectural features, or producing controlled spotlight effects.
The integrated cutting shutters provide precise beam shaping, while the included gobo holder and gobos enable creative pattern projection. A 90° rotatable lens barrel allows users to adjust beam orientation without repositioning shutters or gobos, streamlining on-set workflow. Built from durable aluminium alloy with passive cooling, the attachment is designed for demanding professional environments while maintaining silent operation suitable for sound-sensitive productions.
Key Features
• Professional projection attachment for Nanlux Evoke series fixtures
• Compatible with Evoke 900C, Evoke 1200, Evoke 1200B, and Evoke 2400B
• Adjustable 15°–30° zoom range for precise beam control
• Focus adjustment for sharp or defocused projections
• Precision aspherical optical lens design
• Significantly increases fixture output and beam intensity
• Delivers up to 7.5× greater illuminance compared to the bare fixture
• Independently adjustable cutting shutters for beam shaping
• 90° rotatable lens barrel for flexible projection orientation
• Includes gobo holder and gobos for pattern projection
• Includes gel frame for colour effects and creative lighting
• Minimises chromatic aberration, distortion, and light loss
• Passive cooling design for silent operation
• Durable aluminium alloy construction
• Supplied with a professional flight case for transport and storage
Specifications
• Model: PJ-NLM-15-30
• Product Type: Projection Attachment
• Compatible Mount: Nanlux NL Mount
• Compatible Fixtures: Evoke 900C, Evoke 1200, Evoke 1200B, Evoke 2400B
• Zoom Range: 15°–30°
• Lens Design: Aspherical optical lens
• Lens Rotation: 90° rotatable barrel
• Beam Shaping: Adjustable cutting shutters
• Construction: Aluminium alloy and nylon
• Colour: Black
• Cooling System: Passive cooling
• Dimensions (Extended at 15°): 62.9 × 51.5 × 39.2 cm
• Dimensions (Retracted at 30°): 51.5 × 45.2 × 39.2 cm
• Weight: 11.85 kg
• Flight Case Weight: 12.55 kg
What’s in the Box
• Nanlux NL Mount Projection Attachment 15–30°
• Front Protective Cover
• Rear Protective Cover
• 4 × A-Size Gobos
• Gobo Holder
• Gel Frame
• Flight Case
• User Documentation
